Specifications

• Output current: up to 1.5 A (minimum), up to 2.2 A (typical)
• Adjustable output voltage range: between 1.2 V and 37 V
• Maximum input-output voltage differential: 40 V
• Internal thermal overload protection
• Internal short-circuit current limiting

Downloads

•  LM317 Adjustable Voltage Regulator Datasheet.pdf
•  LM317 Schematic Diagram.pdf
